The M270QAN02.0 CELL launched by AUO is a 27.0-inch LCD glass product using a-Si TFT-LCD technology. It has no backlight, no backlight driver, and no touch. The typical features of the screen library are: inverted terminals, 10 bit grayscale, surface matte finish, TCO 7.0 compliance. Its working temperature is 0~50 ° C and storage temperature is -20~60 ° C. This model is suitable for use in computer monitors. This product has been bonded with 8 source chips driver IC. According to the product specification document Ver1.0 released by AU on February 13, 2017, the M270QAN02.0 CELL has a display resolution of 3840 (RGB) × 2160 (UHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 596.16 × 335.34 (width × height) mm, and its appearance size is 608.3 (width) × 349.3 (height) × 1.3 (thickness) mm. The surface treatment is matte, Hard coating (3H)， The product has a net weight of 660g (Typ.) and uses a glass substrate of 0.50+0.50mm. This product has no backlight and does not include backlight drivers. The M270QAN02.0 CELL adopts eDP (8 Lanes) signal interface, with a total of 51 pins, connected by terminals, and a screen driving voltage of 12.0V (Typ.). Its typical vertical refresh rate Fv is 65Hz.

M270QAN02.0 is a 27.0-inch a-Si TFT-LCD LCD module product launched by AU. It is equipped with WLED backlight, no backlight driver, and no touch. The working temperature of this product is 0-50 ° C, the storage temperature is -20~60 ° C, and the vibration resistance is 1.5G (14.7 m/s ²). Its typical feature screen library is summarized as: sRGB, white LED backlight, inverted terminals, 10 bit grayscale, surface matte, NVIDIA G-Sync， TCO 7.0 Compliance, G-Sync。 Based on its feature screen library, this model is recommended for use in products such as computer monitors. According to the product specification document Ver0.2 released by AUO on March 3, 2016, the M270QAN02.0 has a display resolution of 3840 (RGB) × 2160 (UHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 596.16 (width) × 335.34 (height) mm, and its appearance size is 613.6 (width) × 356.85 (height) × 15 (thickness) mm. The visible size is 601.96 (width) × 340.16 (height) mm, and the surface treatment is matte, Hard coating (3H)， The net weight of the product is 2.82Kgs (Typ.). In terms of backlight, this product adopts a side entry light source (bottom) with 18S4P WLED emission, and the service life of the light source is 30K hours, without backlight driver. M270QAN02.0 adopts eDP (8 Lanes) signal interface, with a total of 51 pins, connected by terminals, and a screen driving voltage of 12.0V (Typ.). Its typical vertical refresh rate Fv is 60Hz.

The LM270WF9-SSA2 (alias: LM270WF9 (SS) (A2)) launched by LG Display is a 27.0-inch LCD module product using a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight driver, and no touch. The typical features of the screen library are: borderless on 3 sides, white LED backlight, inverted terminals, and 3-side borderless. Its working temperature is 0~50 ° C and storage temperature is -20~60 ° C. This model is suitable for use in computer monitors and games. The display resolution of LM270WF9-SSA2 is 1920 (RGB) × 1080 (FHD), with an aspect ratio of 16:9 (width: height), and the pixels are arranged vertically in RGB stripes. Its display area size is 596.736 × 335.664 (width × height) mm, and its appearance size is 608.8 (width) × 355.1 (height) × 15.4 (thickness) mm. The surface treatment is Hard coating (3H). In terms of backlighting, this product uses a WLED side entry light source (bottom) with a lifespan of 30K hours and does not include backlight drivers. LM270WF9-SSA2 adopts eDP (4 Lanes) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 10.0V (Typ.).

M270DAN07.7 CELL is a 27.0-inch a-Si TFT-LCD liquid crystal glass product launched by AUO, which has no backlight and no touch. The working temperature of this product is 0-50 ° C, the storage temperature is -20~60 ° C, and the vibration resistance is 1.5G (14.7 m/s ²). Its typical feature screen library is summarized as: borderless on 3 sides, with a matte surface. Based on its feature screen library, this model is recommended for use in products such as computer monitors. This product has been bonded with 8 source chips driver IC. According to the product specification document Ver0.2 released by AU on April 25, 2023, the M270DAN07.7 CELL has a display resolution of 2560 (RGB) × 1440 (Quad HD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 596.736 (width) × 335.664 (height) mm, and its appearance size is 608.336 (width) × 350.164 (height) × 1.34 (thickness) mm. The surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 651 g (Typ.), using a glass substrate of 0.50+0.50 mm. This product has no backlight. The M270DAN07.7 CELL adopts LVDS (4 ch, 8-bit) signal interface, with a total of 92 pins, connected by terminals, and a screen driving voltage of 10V (Typ.). Its typical vertical refresh rate Fv is 100Hz.

M270DAN07.7 is a 27.0-inch LCD module product launched by AU Optronics Corporation (AUO) using a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight driver, and no touch. According to the product specification document Ver0.2 released by AU on January 23, 2024, the M270DAN07.7 has a display resolution of 2560 (RGB) × 1440 (Quad HD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 596.736 × 335.664 (width × height) mm, and its appearance size is 608.8 × 355.3 (width × height) × 15.4 (thickness) mm. The surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 3.25/3.42Kgs (Typ./Max.). In terms of backlight, this product uses an 18S4P WLED side entry light source with a lifespan of 30K hours and does not include backlight drivers. M270DAN07.7 adopts LVDS (4 ch, 8-bit) signal interface, with a total of 92 pins, connected by terminals, and a screen driving voltage of 10V (Typ.). Its typical vertical refresh rate Fv is 100Hz.

M270DCA-E5B is a 27.0-inch a-Si TFT-LCD LCD module product launched by Innolux. It is equipped with WLED backlight, no backlight driver, and no touch. The working temperature of this product is 0-50 ° C, the storage temperature is -20~60 ° C, and the vibration resistance is 1.5G (14.7 m/s ²). Its typical feature screen library is summarized as: sRGB, 3-side borderless, white LED backlight, 10 bit grayscale, surface matte, TCO9.0, ES8.0, LBL, 3-side Borderless. Based on its features, this model is recommended for use in products such as computer monitors. According to the intelligence obtained by the screen library, this product will be mass-produced in Q4 2023, and the current production status is in mass production. The M270DCA-E5B has a display resolution of 3840 (RGB) × 2160 (UHD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 596.736 (width) × 335.664 (height) mm, and its appearance size is 608.8 (width) × 355.3 (height) × 12.8 (thickness) mm. The surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 2.92/3.07Kgs (Typ./Max.). In terms of backlight, this product uses a WLED side entry light source with a lifespan of 30K hours and does not include backlight drivers. M270DCA-E5B adopts eDP (4 Lanes) signal interface, with a total of 51 pins, connected by terminals, and a screen driving voltage of 12.0V (Typ.). Its typical vertical refresh rate Fv is 60Hz.

LM270WQ6-SSA1 (alias: LM270WQ6 (SS) (A1)) is a 27.0-inch LCD module product launched by LG Display, which adopts a-Si TFT-LCD technology. It is equipped with GB-R LED backlight, no backlight driver, and no touch. According to the product specification document Ver0.3 released by LG Display on September 16, 2015, the LM270WQ6-SSA1 has a display resolution of 2560 (RGB) × 1440 (Quad HD), an aspect ratio of 16:9 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 596.736 × 335.664 (width × height) mm, and its appearance size is 608.8 × 355.3 (width × height) × 17.6 (thickness) mm. The surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 2.60/2.73Kgs (Typ./Max.). In terms of backlight, this product adopts a side entry light source with 4 strings × 2CN GB-R LED emission, and the service life of the light source is 30K hours, without backlight driver. LM270WQ6-SSA1 adopts LVDS (4 ch, 10 bit) signal interface, with a total of 92 pins, connected by terminals, and a screen driving voltage of 10.0V (Typ.). Its typical vertical refresh rate Fv is 60Hz.

The LM270WF7-SSD3 (alias: LM270WF7 (SS) (D3)) launched by LG Display is a 27.0-inch LCD module product using a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight driver, and no touch. The typical features of the screen library are: borderless on 3 sides, white LED backlight, inverted terminals, matte surface, and 3-side borderless. Its working temperature is 0~50 ° C and storage temperature is -20~60 ° C. This model is suitable for use in computer monitors. The display resolution of LM270WF7-SSD3 is 1920 (RGB) × 1080 (FHD), with an aspect ratio of 16:9 (width: height), and the pixels are arranged vertically in RGB stripes. Its display area size is 597.888 × 336.312 (width × height) mm, and its appearance size is 607.1 (width) × 354.1 (height) × 13.6 (thickness) mm. The surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 3.12/3.27Kgs (Typ./Max.). In terms of backlight, this product adopts a 17S4P WLED side entry light source (bottom) with a lifespan of 30K hours, without backlight driver. LM270WF7-SSD3 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 75Hz
