SN215CS01-2 21.5" LCD Glass Screen Display IPS FHD

$88.00

7 Views

SN215CS01-2   A 21.5-inch LCD glass product using Oxide TFT-LCD technology, which has no backlight, no touch, and has been bonded with 6 source chips driver IC.

Get a Quote

Category :

21.5-inch LCD screen

Description

The display resolution of SN215CS01-2 is 1920 (RGB) × 1080 (FHD), with an aspect ratio of 16:9 (width: height), and the pixels are arranged vertically in RGB stripes. Its display area size is 476.064 × 267.786 (width × height) mm, and its appearance size is 483.464 × 278.582 (width × height) × 1.17 (thickness) mm. The surface treatment is matte (Haze 25%), Hard coating (3H), and the net weight of the product is 355g (Typ.). It uses a glass substrate of 0.40+0.40mm. This product has no backlight. SN215CS01-2 adopts LVDS (2 ch, 8-bit) signal interface and terminal connection, with a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 100Hz.
